Cross Runner
Anshidadi Cross Runner is a key component of suspended ceiling systems, working with main runners to form a stable framework and provide reliable support for gypsum boards, mineral wool boards, and other decorative panels. Made of high-quality galvanized steel strips through cold roll forming, our cross runners are available in 50/60 series with thickness ranging from 0.35mm to 0.6mm. Zinc coating can be customized between Z30-Z275, and the standard length is 3000mm with full customization options to meet diverse project needs. Widely used in commercial offices, residential buildings, hospitals, and shopping malls, they combine lightweight design with high strength.
- Overview
- Recommended Products
Why Choose Us
EXPERIENCED
Anshidadi was founded in 1997 and has been deeply involved in the building materialsindustry for 29 years.
PROFESSIONAL SERVICES
We have obtained international professional certifcations like CE,ensuring professionalproduction and efficient after-sales service.
STRICT QUALITY INSPECTION
Our professional quality inspectors and testing instruments inspect the zinc layer, thicknessspecifications, etc.
Specifications:
Cross Runner | |||||
| A(mm) | B(mm) | Thickness(mm) | Zinc plating | Length(mm) | |
 |
50 | 17.5 | 0.35/0.4 | Z30-Z275 | 3000 or customize |
| 18 | 0.4/0.43/0.45/0.5 | ||||
| 19 | 0.45/0.5 | ||||
| 20 | 0.6 | ||||
| 60 | 27 | 0.5/0.6 | |||
Competitive Advantage:
· True Thickness: We adhere to "nominal thickness = actual thickness" for all sizes from 0.35mm to 0.6mm, ensuring structural stability and avoiding ceiling deformation.
· Sufficient Zinc Coating: Customizable zinc coating (Z30-Z275) provides excellent corrosion resistance, extending product lifespan even in harsh environments.
· Full Customization: Besides standard 3000mm length, we support full customization of dimensions to reduce on-site cutting waste and meet project-specific requirements.
· Reliable Quality: Stable batch production meets national and industry standards, and is fully compatible with ANSHIDADI's complete range of ceiling keel products.
